Fix Stages

Reading the Model Configuration*Scroll to confirm.
TTHK CHUO LStage type STravel direction - TStage type 40stage surface 52Design symbol FXFix stage
  L…Linear S…Single   T…Thin type 25…□25
R…Rotary D…Double P…permeation type 40…□40
T…Tilt V…Z lift No Symbol…Normal type 60…□60
51…
Select Linear type
Select Rotary type
Select Permeation type
Select Goniometer type

Center of rotation 60mm

52…
Select Thin type
Select Goniometer type

Center of rotation 40mm

Line Up

X Stage

XY Stage

Thin Type X Stage

Thin Type X Stage
  • X Axis
TLS-T4052FX
(Stage surface:40㎜×40㎜)
TLS-T6052FX
(Stage surface:60㎜×60㎜)

Thin Type XY Stage

Thin Type XY Stage
  • XY Axis
TLD-T4052FX
(Stage surface:40㎜×40㎜)
TLD-T6052FX
(Stage surface:60㎜×60㎜)

Goniometer Stage

2-Axis Goniometer Stage

Transmission Rotary Stage

Transmission Rotary Stage
  • Rotation
TRS-P4051FX
(Stage surface:40㎜×40㎜)
TRS-P6051FX
(Stage surface:60㎜×60㎜)

Z Lift Stage

Transmission Type X Stage

Transmission Type X Stage
  • X Axis
TLS-P4051FX
(Stage surface:40㎜×40㎜)
TLS-P6051FX
(Stage surface:60㎜×60㎜)

Transmission Type XY Stage

Transmission Type XY Stage
  • XY Axis
TLD-P4051FX
(Stage surface:40㎜×40㎜)
TLD-P6051FX
(Stage surface:60㎜×60㎜)

Rotary Stage

Transmission Type XY Stage
  • Rotation
TRS-P2551FX
(Stage surface:25㎜×25㎜)

2-Axis Tilt Stage for Alignment

Transmission Type XY Stage
  • Tilt Double
TTD-A4051FX
(Stage surface:40㎜×40㎜)
TTD-A6051FX
(Stage surface:60㎜×60㎜)

Manual Stages

High-Grade Aluminum Stages

X Stage

X Stage
  • X Axis
TLS-3047-C1
(Stage surface:30㎜×30㎜)
Standard type, Center position, Standard micrometer
TLS-3047-CR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Standard micrometer
TLS-3047-C8
(Stage surface:30㎜×30㎜)
Standard type, Center position, Fine pitch micrometer
TLS-3047-CR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-3047-S1
(Stage surface:30㎜×30㎜)
Standard type, Side position, Standard micrometer
TLS-3047-SR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Standard micrometer
TLS-3047-S8
(Stage surface:30㎜×30㎜)
Standard type, Side position, Fine pitch micrometer
TLS-3047-SR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-4047-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLS-4047-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLS-4047-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLS-4047-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLS-4047-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLS-4047-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-4047-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLS-4047-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLS-4047-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLS-4047-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLS-4047-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLS-4047-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-5047-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLS-5047-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLS-5047-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLS-5047-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLS-5047-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLS-5047-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-5047-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLS-5047-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLS-5047-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLS-5047-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLS-5047-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLS-5047-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-6047-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLS-6047-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLS-6047-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLS-6047-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLS-6047-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLS-6047-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-6047-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLS-6047-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLS-6047-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLS-6047-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLS-6047-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLS-6047-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-7047-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLS-7047-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLS-7047-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLS-7047-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLS-7047-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLS-7047-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-7047-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLS-7047-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLS-7047-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLS-7047-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLS-7047-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLS-7047-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer

XY Stage

XY Stage
  • XY Axis
TLD-3047-C1
(Stage surface:30㎜×30㎜)
Standard type, Center position, Standard micrometer
TLD-3047-CR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Standard micrometer
TLD-3047-C8
(Stage surface:30㎜×30㎜)
Standard type, Center position, Fine pitch micrometer
TLD-3047-CR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-3047-S1
(Stage surface:30㎜×30㎜)
Standard type, Side position, Standard micrometer
TLD-3047-SR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Standard micrometer
TLD-3047-S8
(Stage surface:30㎜×30㎜)
Standard type, Side position, Fine pitch micrometer
TLD-3047-SR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-4047-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLD-4047-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLD-4047-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLD-4047-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLD-4047-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLD-4047-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-4047-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLD-4047-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLD-4047-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLD-4047-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLD-4047-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLD-4047-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-5047-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLD-5047-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLD-5047-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLD-5047-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLD-5047-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLD-5047-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-5047-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLD-5047-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLD-5047-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLD-5047-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLD-5047-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLD-5047-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-6047-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLD-6047-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLD-6047-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLD-6047-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLD-6047-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLD-6047-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-6047-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLD-6047-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLD-6047-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLD-6047-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLD-6047-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLD-6047-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-7047-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLD-7047-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLD-7047-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLD-7047-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLD-7047-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLD-7047-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-7047-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLD-7047-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLD-7047-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLD-7047-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLD-7047-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLD-7047-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer

Z Stage

Z Stage
  • Z Axis
TLZ-3047-C1
(Stage surface:30㎜×30㎜)
Standard type, Center position, Standard micrometer
TLZ-3047-CR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-3047-C8
(Stage surface:30㎜×30㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-3047-CR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-3047-S1
(Stage surface:30㎜×30㎜)
Standard type, Side position, Standard micrometer
TLZ-3047-SR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-3047-S8
(Stage surface:30㎜×30㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-3047-SR8
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-4047-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLZ-4047-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-4047-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLZ-4047-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLZ-4047-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-4047-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-4047-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLZ-4047-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-4047-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLZ-4047-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLZ-4047-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-4047-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-5047-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLZ-5047-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-5047-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLZ-5047-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLZ-5047-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-5047-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-5047-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLZ-5047-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-5047-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLZ-5047-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLZ-5047-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-5047-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-6047-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLZ-6047-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-6047-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLZ-6047-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLZ-6047-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-6047-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-6047-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLZ-6047-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-6047-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLZ-6047-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLZ-6047-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-6047-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-7047-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLZ-7047-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-7047-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLZ-7047-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLZ-7047-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-7047-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-7047-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLZ-7047-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-7047-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLZ-7047-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLZ-7047-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-7047-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer

Rotary Stage

Rotary Stage
  • Rotation
TRS-4012
(Stage surface:φ40㎜) Standard micrometer
TRS-4012-R
(Stage surface:φ40㎜)
reversed micrometer position, Standard micrometer
TRS-5012
(Stage surface:φ50㎜) Standard micrometer
TRS-5012-R
(Stage surface:φ50㎜)
reversed micrometer position, Standard micrometer
TRS-6012
(Stage surface:φ60㎜) Standard micrometer
TRS-6012-R
(Stage surface:φ60㎜)
reversed micrometer position, Standard micrometer
TRS-6042
(Stage surface:φ60㎜) Standard micrometer
TRS-6042-R
(Stage surface:φ60㎜)
reversed micrometer position, Standard micrometer
TRS-7012
(Stage surface:φ70㎜) Standard micrometer
TRS-7012-R
(Stage surface:φ70㎜)
reversed micrometer position, Standard micrometer
TRS-7042
(Stage surface:φ70㎜) Standard micrometer
TRS-7042-R
(Stage surface:φ70㎜)
reversed micrometer position, Standard micrometer

XYZ Stage

XYZ Stage
  • XYZ Axis
TLT-3047-S1
(Stage surface:30㎜×30㎜)
Standard type, Side position, Standard micrometer
TLT-3047-SR1
(Stage surface:30㎜×30㎜)
Symmetrical type, Side position, Standard micrometer
TLT-4047-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLT-4047-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLT-5047-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLT-5047-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLT-6047-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLT-6047-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLT-7047-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLT-7047-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer

XYZ Rotary Stage

XYZ Rotary Stage
  • XYZ Axis
  • Rotation
TTR-3047-S1
(Stage surface:φ30㎜)
Standard type, Side position, Standard micrometer
TTR-3047-SR1
(Stage surface:φ30㎜)
Symmetrical type, Side position, Standard micrometer
TTR-4047-S1
(Stage surface:φ40㎜)
Standard type, Side position, Standard micrometer
TTR-4047-SR1
(Stage surface:φ40㎜)
Symmetrical type, Side position, Standard micrometer
TTR-5047-S1
(Stage surface:φ50㎜)
Standard type, Side position, Standard micrometer
TTR-5047-SR1
(Stage surface:φ50㎜)
Symmetrical type, Side position, Standard micrometer
TTR-6047-S1
(Stage surface:φ60㎜)
Standard type, Side position, Standard micrometer
TTR-6047-SR1
(Stage surface:φ60㎜)
Symmetrical type, Side position, Standard micrometer
TTR-7047-S1
(Stage surface:φ70㎜)
Standard type, Side position, Standard micrometer
TTR-7047-SR1
(Stage surface:φ70㎜)
Symmetrical type, Side position, Standard micrometer

High-Grade Stages (Stainless Steel)

X Stage

X Stage
  • X Axis
TLS-4042-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLS-4042-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLS-4042-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLS-4042-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLS-4042-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLS-4042-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-4042-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLS-4042-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLS-4042-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLS-4042-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLS-4042-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLS-4042-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-4042-S1-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLS-4042-SR1-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLS-4042-S6-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLS-4042-SR6-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLS-4042-S8-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-4042-SR8-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-5042-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLS-5042-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLS-5042-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLS-5042-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLS-5042-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLS-5042-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-5042-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLS-5042-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLS-5042-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLS-5042-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLS-5042-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLS-5042-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-5042-S1-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLS-5042-SR1-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLS-5042-S6-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLS-5042-SR6-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLS-5042-S8-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-5042-SR8-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-6042-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLS-6042-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLS-6042-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLS-6042-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLS-6042-C7
(Stage surface:60㎜×60㎜)
Standard type, Center position, Digimatic micrometer
TLS-6042-CR7
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Digimatic micrometer
TLS-6042-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLS-6042-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-6042-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLS-6042-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLS-6042-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLS-6042-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLS-6042-S7
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometer
TLS-6042-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLS-6042-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-6042-S1-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLS-6042-SR1-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLS-6042-S6-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLS-6042-SR6-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLS-6042-S7-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLS-6042-S8-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-6042-SR8-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-7042-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLS-7042-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLS-7042-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLS-7042-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLS-7042-C7
(Stage surface:70㎜×70㎜)
Standard type, Center position, Digimatic micrometer
TLS-7042-CR7
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Digimatic micrometer
TLS-7042-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLS-7042-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLS-7042-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLS-7042-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLS-7042-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLS-7042-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLS-7042-S7
(Stage surface:70㎜×70㎜)
Standard type, Side position, Digimatic micrometer
TLS-7042-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLS-7042-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLS-7042-S1-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLS-7042-SR1-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLS-7042-S6-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLS-7042-SR6-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLS-7042-S7-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLS-7042-S8-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLS-7042-SR8-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp

XY Stage

XY Stage
  • XY Axis
TLD-4042-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLD-4042-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLD-4042-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLD-4042-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLD-4042-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLD-4042-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-4042-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLD-4042-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLD-4042-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLD-4042-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLD-4042-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLD-4042-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-4042-S1-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLD-4042-SR1-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLD-4042-S6-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLD-4042-SR6-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLD-4042-S8-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-4042-SR8-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-5042-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLD-5042-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLD-5042-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLD-5042-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLD-5042-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLD-5042-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-5042-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLD-5042-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLD-5042-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLD-5042-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLD-5042-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLD-5042-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-5042-S1-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLD-5042-SR1-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLD-5042-S6-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLD-5042-SR6-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLD-5042-S8-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-5042-SR8-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-6042-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLD-6042-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLD-6042-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLD-6042-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLD-6042-C7
(Stage surface:60㎜×60㎜)
Standard type, Center position, Digimatic micrometer
TLD-6042-CR7
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Digimatic micrometer
TLD-6042-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLD-6042-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-6042-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLD-6042-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLD-6042-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLD-6042-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLD-6042-S7
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometer
TLD-6042-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLD-6042-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-6042-S1-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLD-6042-SR1-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLD-6042-S6-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLD-6042-SR6-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLD-6042-S7-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLD-6042-S8-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-6042-SR8-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-7042-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLD-7042-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLD-7042-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLD-7042-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLD-7042-C7
(Stage surface:70㎜×70㎜)
Standard type, Center position, Digimatic micrometer
TLD-7042-CR7
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Digimatic micrometer
TLD-7042-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLD-7042-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLD-7042-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLD-7042-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLD-7042-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLD-7042-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLD-7042-S7
(Stage surface:70㎜×70㎜)
Standard type, Side position, Digimatic micrometer
TLD-7042-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLD-7042-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLD-7042-S1-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLD-7042-SR1-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLD-7042-S6-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLD-7042-SR6-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLD-7042-S7-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLD-7042-S8-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLD-7042-SR8-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp

Z Stage

Z Stage
  • Z Axis
TLZ-4042-C1
(Stage surface:40㎜×40㎜)
Standard type, Center position, Standard micrometer
TLZ-4042-CR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-4042-C6
(Stage surface:40㎜×40㎜)
Standard type, Center position, Feed screw
TLZ-4042-CR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Feed screw
TLZ-4042-C8
(Stage surface:40㎜×40㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-4042-CR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-4042-S1
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer
TLZ-4042-SR1
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-4042-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLZ-4042-SR6
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw
TLZ-4042-S8
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-4042-SR8
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-4042-S1-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLZ-4042-SR1-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLZ-4042-S6-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLZ-4042-SR6-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLZ-4042-S8-2
(Stage surface:40㎜×40㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-4042-SR8-2
(Stage surface:40㎜×40㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-5042-C1
(Stage surface:50㎜×50㎜)
Standard type, Center position, Standard micrometer
TLZ-5042-CR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-5042-C6
(Stage surface:50㎜×50㎜)
Standard type, Center position, Feed screw
TLZ-5042-CR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Feed screw
TLZ-5042-C8
(Stage surface:50㎜×50㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-5042-CR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-5042-S1
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer
TLZ-5042-SR1
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-5042-S6
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw
TLZ-5042-SR6
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw
TLZ-5042-S8
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-5042-SR8
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-5042-S1-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLZ-5042-SR1-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLZ-5042-S6-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLZ-5042-SR6-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLZ-5042-S8-2
(Stage surface:50㎜×50㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-5042-SR8-2
(Stage surface:50㎜×50㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-6042-C1
(Stage surface:60㎜×60㎜)
Standard type, Center position, Standard micrometer
TLZ-6042-CR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-6042-C6
(Stage surface:60㎜×60㎜)
Standard type, Center position, Feed screw
TLZ-6042-CR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Feed screw
TLZ-6042-C7
(Stage surface:60㎜×60㎜)
Standard type, Center position, Digimatic micrometer
TLZ-6042-CR7
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Digimatic micrometer
TLZ-6042-C8
(Stage surface:60㎜×60㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-6042-CR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-6042-S1
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer
TLZ-6042-SR1
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-6042-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLZ-6042-SR6
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw
TLZ-6042-S7
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometer
TLZ-6042-S1-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLZ-6042-SR1-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLZ-6042-S6-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLZ-6042-SR6-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLZ-6042-S7-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLZ-7042-C1
(Stage surface:70㎜×70㎜)
Standard type, Center position, Standard micrometer
TLZ-7042-CR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Standard micrometer
TLZ-7042-C6
(Stage surface:70㎜×70㎜)
Standard type, Center position, Feed screw
TLZ-7042-CR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Feed screw
TLZ-7042-C7
(Stage surface:70㎜×70㎜)
Standard type, Center position, Digimatic micrometer
TLZ-7042-CR7
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Digimatic micrometer
TLZ-7042-C8
(Stage surface:70㎜×70㎜)
Standard type, Center position, Fine pitch micrometer
TLZ-7042-CR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Center position, Fine pitch micrometer
TLZ-7042-S1
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer
TLZ-7042-SR1
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer
TLZ-7042-S6
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw
TLZ-7042-SR6
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw
TLZ-7042-S7
((Stage surface:70㎜×70㎜)
(Standard type, Side position, Digimatic micrometer
TLZ-7042-S1-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Standard micrometer, Operator side plate clamp
TLZ-7042-SR1-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Standard micrometer, Operator side plate clamp
TLZ-7042-S6-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Feed screw, Operator side plate clamp
TLZ-7042-SR6-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Feed screw, Operator side plate clamp
TLZ-7042-S7-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Digimatic micrometr, Operator side plate clamp
TLZ-6042-S8
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-6042-SR8
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer
TLZ-6042-S8-2
(Stage surface:60㎜×60㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-6042-SR8-2
(Stage surface:60㎜×60㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-7042-S8
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer
TLZ-7042-S8-2
(Stage surface:70㎜×70㎜)
Standard type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-7042-SR8-2
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer, Operator side plate clamp
TLZ-7042-SR8
(Stage surface:70㎜×70㎜)
Symmetrical type, Side position, Fine pitch micrometer

Z Lift Stage

Z Lift Stage
  • Z Axis
TLV-3047-1
(Stage surface:30㎜×30㎜)
Standard type, Standard micrometer
TLV-4042-1
(Stage surface:40㎜×40㎜)
Standard type, Standard micrometer
TLV-4042-6
(Stage surface:40㎜×40㎜) Standard type, Feed screw
TLV-4042-8
(Stage surface:40㎜×40㎜)
Standard type, Fine pitch micrometer
TLV-5042-1
(Stage surface:50㎜×50㎜)
Standard type, Standard micrometer
TLV-5042-6
(Stage surface:50㎜×50㎜) Standard type, Feed screw
TLV-5042-8
(Stage surface:50㎜×50㎜)
Standard type, Fine pitch micrometer
TLV-6042-1
(Stage surface:60㎜×60㎜)
Standard type, Standard micrometer
TLV-6042-6
(Stage surface:60㎜×60㎜) Standard type, Feed screw
TLV-6042-7
(Stage surface:60㎜×60㎜)
Standard type, Digimatic micrometer
TLV-6042-8
(Stage surface:60㎜×60㎜)
Standard type, Fine pitch micrometer
TLV-7042-1
(Stage surface:70㎜×70㎜)
Standard type, Standard micrometer
TLV-7042-6
(Stage surface:70㎜×70㎜) Standard type, Feed screw
>TLV-7042-7
(Stage surface:70㎜×70㎜)
Standard type, Digimatic micrometer
TLV-7042-8
(Stage surface:70㎜×70㎜)
Standard type, Fine pitch micrometer

Thin VB Stages

X, XY Stage

X, XY Stage
  • X Axis
  • XY Axis
TLS-T4039-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLS-T6039-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw
TLD-T4039-S6
(Stage surface:40㎜×40㎜)
Standard type, Side position, Feed screw
TLD-T6039-S6
(Stage surface:60㎜×60㎜)
Standard type, Side position, Feed screw

Slim Stages, Cross Roller Stages

X, XY Stage

X, XY Stage
  • X Axis
  • XY Axis
TLS-947-C1
(Stage surface:90㎜×90㎜)
Standard type, Center position, Standard micrometer
TLS-947-S1
(Stage surface:90㎜×90㎜)
Standard type, Side position, Standard micrometer
TLS-947-R1
(Stage surface:90㎜×90㎜)
Reversed micrometer position, Standard micrometer
TLS-149-C1
(Stage surface:125㎜×125㎜)
Standard type, Center position, Standard micrometer
TLS-149-S1
(Stage surface:125㎜×125㎜)
Standard type, Side position, Standard micrometer
TLS-149-R1
(Stage surface:125㎜×125㎜)
Reversed micrometer position, Standard micrometer
TLS-149-C7
(Stage surface:125㎜×125㎜)
Standard type, Center position, Digimatic micrometer
TLS-149-S7
(Stage surface:125㎜×125㎜)
Standard type, Side position, Digimatic micrometer
TLS-241-C1
(Stage surface:125㎜×150㎜)
Standard type, Center position, Standard micrometer
TLS-241-S1
(Stage surface:125㎜×150㎜)
Standard type, Side position, Standard micrometer
TLS-243-C7
(Stage surface:125㎜×150㎜)
Standard type, Center position, Digimatic micrometer
TLS-242-MSC
(Stage surface:130㎜×200㎜)
Manual feed, Magnetic scale or display unit included
TLD-947-C1
(Stage surface:90㎜×90㎜)
Standard type, Center position, Standard micrometer
TLD-947-S1
(Stage surface:90㎜×90㎜)
Standard type, Side position, Standard micrometer
TLD-947-R1
(Stage surface:90㎜×90㎜)
Reversed micrometer position, Standard micrometer
TLD-149-C1
(Stage surface:125㎜×125㎜)
Standard type, Center position, Standard micrometer
TLD-149-S1
(Stage surface:125㎜×125㎜)
Standard type, Side position, Standard micrometer
TLD-149-R1
(Stage surface:125㎜×125㎜)
Reversed micrometer position, Standard micrometer
TLD-149-C7
(Stage surface:125㎜×125㎜)
Standard type, Center position, Digimatic micrometer
TLD-149-S7
(Stage surface:125㎜×125㎜)
Standard type, Side position, Digimatic micrometer
TLD-241-C1
(Stage surface:125㎜×150㎜)
Standard type, Center position, Standard micrometer
TLD-241-S1
(Stage surface:125㎜×150㎜)
Standard type, Side position, Standard micrometer
TLD-243-C7
(Stage surface:125㎜×150㎜)
Standard type, Center position, Digimatic micrometer
TLD-242
(Stage surface:130㎜×200㎜) Center position, Manual feed
TLD-242-MSC
(Stage surface:130㎜×200㎜)
Center position, Manual feed, Magnetic scale or display unit included
TLS-242
(Stage surface:130㎜×200㎜) Center position, Manual feed

Z Stage

Z Stage
  • Z Axis
TLZ-947-S1
(Stage surface:90㎜×90㎜)
Standard type, Side position, Standard micrometer
TLZ-947-R1
(Stage surface:90㎜×90㎜)
Reversed micrometer position, Standard micrometer

XYZ Stage

XYZ Stage
  • XYZ Axis
TLT-907-S1
(Stage surface:90㎜×90㎜)
Standard type, Side position, Standard micrometer
TLT-907-R1
(Stage surface:90㎜×90㎜)
Reversed micrometer position, Standard micrometer
TLT-140-S1
(Stage surface:125㎜×125㎜)
Standard type, Side position, Standard micrometer
TLT-140-R1
(Stage surface:125㎜×125㎜)
Reversed micrometer position, Standard micrometer

XYZ Rotary Stage

XYZ Rotary Stage
  • XYZ Axis
  • Rotation
TTR-907-S1
(Stage surface:Φ90㎜)
Standard type, Side position, Standard micrometer
TTR-907-R1
(Stage surface:Φ90㎜)
Reversed micrometer position, Standard micrometer
TTR-101-S1
(Stage surface:Φ125㎜)
Standard type, Side position, Standard micrometer
TTR-101-R1
(Stage surface:Φ125㎜)
Reversed micrometer position, Standard micrometer

Z Lift Stage

Z Lift Stage
  • Z Axis
TLV-147-1
(Stage surface:125㎜×125㎜)
Standard type, Standard micrometer
TLV-147-6
(Stage surface:125㎜×125㎜) Standard type, Feed screw
TLV-147-7
(Stage surface:125㎜×125㎜)
Standard type, Digimatic micrometer

Rack & Pinion Stages

X Stage

X Stage
  • X Axis
TLS-412
(Stage surface:40㎜×40㎜) Single knob
TLS-412W
(Stage surface:40㎜×40㎜) Double knob
TLS-412S
(Stage surface:40㎜×40㎜)
Single coarse/fine movement knob
TLS-412WS
(Stage surface:40㎜×40㎜)
Double coarse/fine movement knob
TLS-612
(Stage surface:40㎜×60㎜) Single knob
TLS-612W
(Stage surface:40㎜×60㎜) Double knob
TLS-612S
(Stage surface:40㎜×60㎜) Single coarse/fine movement knob
TLS-612WS
(Stage surface:40㎜×60㎜)
Double coarse/fine movement knob
TLS-912
(Stage surface:40㎜×90㎜) Single knob
TLS-912W
(Stage surface:40㎜×90㎜) Double knob
TLS-912S
(Stage surface:40㎜×90㎜)
Single coarse/fine movement knob
TLS-912WS
(Stage surface:40㎜×90㎜)
Double coarse/fine movement knob
TLS-112
(Stage surface:40㎜×140㎜) Single knob
TLS-112W
(Stage surface:40㎜×140㎜) Double knob
TLS-112S
(Stage surface:40㎜×140㎜)
Single coarse/fine movement knob
TLS-112WS
(Stage surface:40㎜×140㎜)
Double coarse/fine movement knob

XY Stage

XY Stage
  • XY Axis
TLD-412
(Stage surface:40㎜×40㎜) Single knob
TLD-412W
(Stage surface:40㎜×40㎜) Double knob
TLD-412S
(Stage surface:40㎜×40㎜)
Single coarse/fine movement knob
TLD-412WS
(Stage surface:40㎜×40㎜)
Double coarse/fine movement knob
TLD-612
(Stage surface:40㎜×60㎜) Single knob
TLD-612W
(Stage surface:40㎜×60㎜) Double knob
TLD-612S
(Stage surface:40㎜×60㎜)
Single coarse/fine movement knob
TLD-612WS
(Stage surface:40㎜×60㎜)
Double coarse/fine movement knob
TLD-912
(Stage surface:40㎜×90㎜) Single knob
TLD-912W
(Stage surface:40㎜×90㎜) Double knob
TLD-912S
(Stage surface:40㎜×90㎜)
Single coarse/fine movement knob
TLD-912WS
(Stage surface:40㎜×90㎜)
Double coarse/fine movement knob
TLD-112
(Stage surface:40㎜×140㎜) Single knob
TLD-112W
(Stage surface:40㎜×140㎜) Double knob
TLD-112S
(Stage surface:40㎜×140㎜)
Single coarse/fine movement knob
TLD-112WS
(Stage surface:40㎜×140㎜)
Double coarse/fine movement knob

Z Stage

Z Stage
  • Z Axis
TLV-412L
(Stage surface:40㎜×40㎜ ) Low bracket, Single knob
TLV-412WL
(Stage surface:40㎜×40㎜) Low bracket, Double knob
TLV-412SL
(Stage surface:40㎜×60㎜)
Low bracket, Single coarse/fine movement knob
TLV-412WSL
(Stage surface:40㎜×60㎜)
Low bracket, Double coarse/fine movement knob
TLV-412
(Stage surface:40㎜×40㎜) Single knob
TLV-412W
(Stage surface:40㎜×40㎜) Double knob
TLV-412S
(Stage surface:40㎜×60㎜) Single coarse/fine movement knob
TLV-412WS
(Stage surface:40㎜×60㎜)
Double coarse/fine movement knob
TLV-612L
(Stage surface:40㎜×60㎜) Low bracket, Single knob
TLV-612WL
(Stage surface:40㎜×60㎜) Low bracket, Double knob
TLV-612SL
(Stage surface:40㎜×60㎜)
Low bracket, Single coarse/fine movement knob
TLV-612WSL
(Stage surface:40㎜×60㎜)
Low bracket, Double coarse/fine movement knob
TLV-612
(Stage surface:40㎜×60㎜) Single knob
TLV-612W
(Stage surface:40㎜×60㎜) Double knob
TLV-612S
(Stage surface:40㎜×60㎜) Single coarse/fine movement knob
TLV-612WS
(Stage surface:40㎜×60㎜)
Double coarse/fine movement knob
TLV-912L
(Stage surface:40㎜×90㎜ ) Low bracket, Single knob
TLV-912WL
(Stage surface:40㎜×90㎜) Low bracket, Double knob
TLV-912SL
(Stage surface:40㎜×90㎜)
Low bracket, Single coarse/fine movement knob
TLV-912WSL
(Stage surface:40㎜×90㎜)
Low bracket, Double coarse/fine movement knob
TLV-912
(Stage surface:40㎜×90㎜) Single knob
TLV-912W
(Stage surface:40㎜×90㎜) Double knob
TLV-912S
(Stage surface:40㎜×90㎜) Single coarse/fine movement knob
TLV-912WS
(Stage surface:40㎜×90㎜)
Double coarse/fine movement knob
TLV-112L
(Stage surface:40㎜×140㎜ ) Low bracket, Single knob
TLV-112WL
(Stage surface:40㎜×140㎜) Low bracket, Double knob
TLV-112SL
(Stage surface:40㎜×140㎜)
Low bracket, Single coarse/fine movement knob
TLV-112WSL
(Stage surface:40㎜×140㎜)
Low bracket, Double coarse/fine movement knob
TLV-112
(Stage surface:40㎜×140㎜) Single knob
TLV-112W
(Stage surface:40㎜×140㎜) Double knob
TLV-112S
(Stage surface:40㎜×140㎜)
Single coarse/fine movement knob
TLV-112WS
(Stage surface:40㎜×140㎜)
Double coarse/fine movement knob

XZ Stage

XZ Stage
  • XZ Axis
TLM-412L
(Stage surface:40㎜×40㎜ ) Low bracket, Single knob
TLM-412WL
(Stage surface:40㎜×40㎜) Low bracket, Double knob
TLM-412SL
(Stage surface:40㎜×40㎜)
Low bracket, Single coarse/fine movement knob
TLM-412WSL
(Stage surface:40㎜×40㎜)
Low bracket, Double coarse/fine movement knob
TLM-412
(Stage surface:40㎜×40㎜) Single knob
TLM-412W
(Stage surface:40㎜×40㎜) Double knob
TLM-412S
(Stage surface:40㎜×40㎜) Single coarse/fine movement knob
TLM-412WS
(Stage surface:40㎜×40㎜)
Double coarse/fine movement knob
TLM-612L
(Stage surface:40㎜×60㎜ ) Low bracket, Single knob
TLM-612WL
(Stage surface:40㎜×60㎜) Low bracket, Double knob
TLM-612SL
(Stage surface:40㎜×60㎜)
Low bracket, Single coarse/fine movement knob
TLM-612WSL
(Stage surface:40㎜×60㎜)
Low bracket, Double coarse/fine movement knob
TLM-612
(Stage surface:40㎜×60㎜) Single knob
TLM-612W
(Stage surface:40㎜×60㎜) Double knob
TLM-612S
(Stage surface:40㎜×60㎜) Single coarse/fine movement knob
TLM-612WS
(Stage surface:40㎜×60㎜)
Double coarse/fine movement knob
TLM-912L
(Stage surface:40㎜×90㎜) Low bracket, Single knob
TLM-912WL
(Stage surface:40㎜×90㎜) Low bracket, Double knob
TLM-912SL
(Stage surface:40㎜×90㎜)
Low bracket, Single coarse/fine movement knob
TLM-912WSL
(Stage surface:40㎜×90㎜)
Low bracket, Double coarse/fine movement knob
TLM-912
(Stage surface:40㎜×90㎜) Single knob
TLM-912W
(Stage surface:40㎜×90㎜) Double knob
TLM-912S
(Stage surface:40㎜×90㎜) Single coarse/fine movement knob
TLM-912WS
(Stage surface:40㎜×90㎜)
Double coarse/fine movement knob
TLM-112L
(Stage surface:40㎜×140㎜ ) Low bracket, Single knob
TLM-112WL
(Stage surface:40㎜×140㎜) Low bracket, Double knob
TLM-112SL
(Stage surface:40㎜×140㎜)
Low bracket, Single coarse/fine movement knob
TLM-112WSL
(Stage surface:40㎜×140㎜)
Low bracket, Double coarse/fine movement knob
TLM-112
(Stage surface:40㎜×140㎜) Single knob
TLM-112W
(Stage surface:40㎜×140㎜) Double knob
TLM-112S
(Stage surface:40㎜×140㎜)
Single coarse/fine movement knob
TLM-112WS
(Stage surface:40㎜×140㎜)
Double coarse/fine movement knob

XYZ Stage

XYZ Stage
  • XYZ Axis
TLT-412L
(Stage surface:40㎜×40㎜ ) Low bracket, Single knob
TLT-412WL
(Stage surface:40㎜×40㎜) Low bracket, Double knob
TLT-412SL
(Stage surface:40㎜×40㎜)
Low bracket, Single coarse/fine movement knob
TLT-412WSL
(Stage surface:40㎜×40㎜)
Low bracket, Double coarse/fine movement knob
TLT-412
(Stage surface:40㎜×40㎜) Single knob
TLT-412W
(Stage surface:40㎜×40㎜) Double knob
TLT-412S
(Stage surface:40㎜×40㎜) Single coarse/fine movement knob
TLT-412WS
(Stage surface:40㎜×40㎜)
Double coarse/fine movement knob
TLT-612L
(Stage surface:40㎜×60㎜ ) Low bracket, Single knob
TLT-612WL
(Stage surface:40㎜×60㎜) Low bracket, Double knob
TLT-612SL
(Stage surface:40㎜×60㎜)
Low bracket, Single coarse/fine movement knob
TLT-612WSL
(Stage surface:40㎜×60㎜)
Low bracket, Double coarse/fine movement knob
TLT-612
(Stage surface:40㎜×60㎜) Single knob
TLT-612W
(Stage surface:40㎜×60㎜) Double knob
TLT-612S
(Stage surface:40㎜×60㎜) Single coarse/fine movement knob
TLT-612WS
(Stage surface:40㎜×60㎜)
(Double coarse/fine movement knob
TLT-912L
(Stage surface:40㎜×90㎜ ) Low bracket, Single knob
TLT-912WL
(Stage surface:40㎜×90㎜) Low bracket, Double knob
TLT-912SL
(Stage surface:40㎜×90㎜)
Low bracket, Single coarse/fine movement knob
TLT-912WSL
(Stage surface:40㎜×90㎜)
Low bracket, Double coarse/fine movement knob
TLT-912
(Stage surface:40㎜×90㎜) Single knob
TLT-912W
(Stage surface:40㎜×90㎜) Double knob
TLT-912S
(Stage surface:40㎜×90㎜) Single coarse/fine movement knob
TLT-912WS
(Stage surface:40㎜×90㎜)
Double coarse/fine movement knob
TLT-112L
(Stage surface:40㎜×140㎜ ) Low bracket, Single knob
TLT-112WL
(Stage surface:40㎜×140㎜) Low bracket, Double knob
TLT-112SL
(Stage surface:40㎜×140㎜)
Low bracket, Single coarse/fine movement knob
TLT-112WSL
(Stage surface:40㎜×140㎜)
Low bracket, Double coarse/fine movement knob
TLT-112
(Stage surface:40㎜×140㎜) Single knob
TLT-112W
(Stage surface:40㎜×140㎜) Double knob
TLT-112S
(Stage surface:40㎜×140㎜)
Single coarse/fine movement knob
TLT-112WS
(Stage surface:40㎜×140㎜)
Double coarse/fine movement knob

Long-Distance Stage

Long-Distance Stage
  • X Axis
TLS-414L1
(Stage surface:40㎜×40㎜) Rail length 100 mm, Single knob
TLS-414WL1
(Stage surface:40㎜×40㎜) Rail length 100 mm, Double knob
TLS-414L2
(Stage surface:40㎜×40㎜) Rail length 200 mm, Single knob
TLS-414WL2
(Stage surface:40㎜×40㎜) Rail length 200 mm, Double knob
TLS-414L3
(Stage surface:40㎜×40㎜) Rail length 300 mm, Single knob
TLS-414WL3
(Stage surface:40㎜×40㎜) Rail length 300 mm, Double knob
TLS-414L4
(Stage surface:40㎜×40㎜) Rail length 400 mm, Single knob
TLS-414WL4
(Stage surface:40㎜×40㎜) Rail length 400 mm, Double knob
TLS-414L5
(Stage surface:40㎜×40㎜) Rail length 500 mm, Single knob
TLS-414WL5
(Stage surface:40㎜×40㎜) Rail length 500 mm, Double knob
TLS-414SL1
(Stage surface:40㎜×40㎜)
Rail length 100 mm, Single coarse/fine movement knob
TLS-414WSL1
(Stage surface:40㎜×40㎜)
Rail length 100 mm, Double coarse/fine movement knob
TLS-414SL2
(Stage surface:40㎜×40㎜)
Rail length 200 mm, Single coarse/fine movement knob
TLS-414WSL2
(Stage surface:40㎜×40㎜)
Rail length 200 mm, Double coarse/fine movement knob
TLS-414SL3
(Stage surface:40㎜×40㎜)
Rail length 300 mm, Single coarse/fine movement knob
TLS-414WSL3
(Stage surface:40㎜×40㎜)
Rail length 300 mm, Double coarse/fine movement knob
TLS-414SL4
(Stage surface:40㎜×40㎜)
Rail length 400 mm, Single coarse/fine movement knob
TLS-414WSL4
(Stage surface:40㎜×40㎜)
Rail length 400 mm, Double coarse/fine movement knob
TLS-414SL5
(Stage surface:40㎜×40㎜)
Rail length 500 mm, Single coarse/fine movement knob
TLS-414WSL5
(Stage surface:40㎜×40㎜)
Rail length 500 mm, Double coarse/fine movement knob

Long-Distance Stage

Long-Distance Stage
  • X Axis
TBL-414
(Stage surface:40㎜×40㎜) Single knob
TBL-414W
(Stage surface:40㎜×40㎜) Double knob
TBL-414S
(Stage surface:40㎜×40㎜) Single coarse/fine movement knob
TBL-414WS
(Stage surface:40㎜×40㎜)
Double coarse/fine movement knob

Z Lift Stages

Z Lift Stage

Z Lift Stage
  • Z Axis
TLV-642-1
(Stage surface:60㎜×60㎜)
Standard type, Standard micrometer
TLV-937-1
(Stage surface:90㎜×90㎜)
Standard type, Standard micrometer

Lab Jacks Stage

Lab Jacks Stage
  • Z Axis
TLV-151-2
(Stage surface:125㎜×125㎜)
TLV-251-2
(Stage surface:150㎜×200㎜)

Z Stages

Z Stages
  • Z Axis
TLV-111
(Stage surface:40㎜×50㎜) Double knob
TLV-643
(Stage surface:60㎜×60㎜)
Double coarse/fine movement knob
TLV-143
(Stage surface:60㎜×115㎜)
Double coarse/fine movement knob
TLV-243
(Stage surface:60㎜×155㎜)
Double coarse/fine movement knob

Rotary Stages

Rotary Stage

Rotary Stage
  • Rotation
TRS-313
(Stage surface:φ30㎜) Standard micrometer
TRS-314T
(Stage surface:φ28㎜) Standard micrometer
TRS-317
(Stage surface:φ30㎜) Standard micrometer
TRS-317-R
(Stage surface:φ30㎜)
Reversed micrometer position, Standard micrometer
